| Place of Origin: | China |
|---|---|
| Brand Name: | Lensen |
| Model Number: | LS-G1000-4G |
| Minimum Order Quantity: | 2pcs |
| Price: | Negotiation |
| Packaging Details: | standard carton |
| Delivery Time: | 2-6 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 6000pcs/month |
| Power Output: | 1W | Freuquency: | 4G |
|---|---|---|---|
| Interface: | RS232/RS485/TTL | Protocol: | Modbus TCP/IP |
| Distance: | Not Limit | Module: | EC25 |
| High Light: | 4g lte modem,4g lte module |
||
1W 4G Wireless Gateway Tcp Ip Modem 4g Lte DTU Sms Modem Gsm Fixed Wireless Module
Specifications:
1)Main Features
Support 4G/3G/2G, Mobile, Telecom and China Unicom;
Bidirectional data transparent transmission between terminals TTL, RS485, RS232, and server;
Support user-defined registration packet and heartbeat ;
Standard TCP/IP communication interface Socket in Server ;
Intelligent anti disconnection, support online testing and online maintenance, disconnected then automatic redial, ensure that the equipment is always online;
Support configuration of the domain name, IP, port number, APN, serial port, baud rate and other parameters through serial port ;
Support remote configuration, remote firmware upgrade;
Support fixed IP and domain name DNS.
2)Technical Parameters
| Type | Parameters | Unit | ||||||
| Minimum | Typical Value | Maximum | ||||||
| Electrical Property (25℃) | ||||||||
| Mains Voltage | 4.75 | 12 | 36 | V | ||||
| Working Current | 70 | 150 | 250 | mA | ||||
| Peak Current | - | - | 2000 | mA | ||||
| Wireless Performance (25℃) | ||||||||
| Frequency Range | 4G 3G 2G | - | ||||||
| Sensitivity | -106dBm | - | ||||||
| Max. Emission Power |
|
- | ||||||
| General Performance | ||||||||
| Interface Rate | 1200 | 9600 | 115200 | bps | ||||
| Interface Level | RS485,RS232,TTL | |||||||
| Working Temperature | -40 | 80 | ℃ | |||||
| Dimension | 52×35×10 (not including antenna and accessories) | mm | ||||||
3) Pin Definition
| Pins | Definition | Input/output | Function Description |
| 1 | VCC | Input | Positive power supply (4.75V-36V) |
| 2 | Rxd_TTL/232 | Input | 3.3V Serial port Input of TTL/RS232 Level |
| 3 | Txd_TTL/232 | Output | 3.3V Serial port Input of TTL/RS232 Level |
| 4 | GND | Input | Negative power supply |
| 5 | SGND | Input | SGND |
